![oneTwo xx.U6Q [U83].jpg](https://global-download.acer.com/Image/ModelPictures/Desktop/oneTwo%20xx.U6Q%20[U83].jpg) |
|
- Summary
- Buy Options
- Help & Support
- Repair Parts / Upgrades
- Downloads
- Specifications
- Warranty
Summary
Want to buy one? Click
◄ [Buy Options]
Need help? Click◄ [Help & Support]
Want to buy service / replacement / upgrade parts? Click◄ [Repair Parts / Upgrades]
Looking for drivers, BIOS utilities or manuals? Click◄ [Downloads]
Need to look up technical specs? Click◄ [Specifications]
Warranty expiry date lookup? Click◄ [Warranty]
Corrupt, damaged or missing operating system (Windows/Linux)? Click◄ [Recovery CD/DVD/USB]
Buy Options
Buy this product from
Buy this product from
Help & Support
Technical Support
In warranty (Limited free support)
• If your device is still under manufacturer's warranty, you are eligible for limited support (free of charge)• Contact your local Packard Bell office
Out of warranty (Premium paid support)
• Warranty expired? You can still get help!• Professional support by Packard Bell trained technicians
• Offered via e-mail or live chat, typical response time is 1-2 hours
• Hardware & software problems
• Upgrades & specifications
• Spare parts search
• Only
• Satisfaction guaranteed, you will only be billed once you approve the answers provided
• Enter your question in the form below to get the process started
Repair Parts / Upgrades
Found 7 parts for M3870_P model (for repairs / spares)
Category | Description | |
|---|---|---|
| ADAPTER | ADAPTER LITE-ON 135W 19V 5.1X7.4X12.5 ORANGE PA-1131-07AD, LV5 LED LF RIGHT ANGLE AC ADAPTOR 135W 19V 7 ORANGE ADAPTER.19V 135W.7.1A.(BUY-ACER).PA-1131-07AD..V.01 LOT 6 2013.W/SAFETY(2000M)...AP.13503.012...LEAD-FREE.LITEON, 82-231-019057 P/N: 0432-01D70PB | |
| BOARD NIC | BOARD WLAN LITE-ON WN6602RH RALINK RT3090 802.11B/G/N 1X1 (MINI-CARD) HALF SIZE P/N: 1HYXZZZ077U | |
| CPU | CPU INTEL CORE I3 2120 LGA 3M 1333 1155 65W 3.3G, DUAL CORE P/N: SR05Y | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA HLDS GT51N LF W/O BEZEL ZERO POWER SUPPORTED (HF + WINDOWS 7) P/N: GT51N | |
| HDD | HDD 1TB 5400RPM SATA 3 64MB 3.5" 4K GREEN WD10EARX WD LF F/W:51.0AB51 P/N: WD10EARX | |
| LCD | LED LCD LPL 21.5"W FHD NONE GLARE LM215WF4 TLE7 LF 250NIT 5MS FAB P8 | |
| MAINBOARD | MAINBOARD PPARIS INTEL H61 REALTEK RTL8111E-VL ACER LOGO PROPRIETARY W/O 1394 V1.0 LF W/I MCR, W/I USB3.0, FOR UMA AND SWITCHABLE VGA P/N: 90M10AIL0010 |
Downloads
Specifications
| Model P/N: | DO.U6QEK.003 / DOU6QEK003 |
| Release date (year): | 2013 |
| Quick specs: | PACKARD BELL ONETWO M I5112 UK oTM3870_P CH EMEA001 W7HP64PUK0108/Ci3-2100/4G*1/1000G*1/NSM8XS/DLED21.5H/single DVB-T/802.11 b/g/n/RF2.4/Godiva/RF2.4/P5_PB |
| Processor & Chipset | |
|---|---|
| Number of Processors Supported: | 1 |
| Number of Processors Installed: | 1 |
| Processor Manufacturer: | Intel |
| Processor Type: | Core i3 |
| Processor Generation: | 2nd Gen |
| Processor Model: | i3-2100 |
| Processor Core: | Dual-core (2 Core) |
| Processor Speed: | 3.10 GHz |
| Cache: | 3 MB |
| Direct Media Interface: | 5 GT/s |
| 64-bit Processing: | Yes |
| Hyper-Threading: | Yes |
| Chipset Manufacturer: | Intel |
| Chipset Model: | H61 Express |
| Memory | |
| Standard Memory: | 4 GB |
| Maximum Memory: | 8 GB |
| Memory Technology: | DDR3 SDRAM |
| Memory Standard: | DDR3-1333/PC3-10600 |
| Number of Total Memory Slots: | 2 |
| Memory Card Reader: | Yes |
| Memory Card Supported: | Memory Stick PRO-HG Duo |
| Storage | |
| Number of Hard Drives: | 1 |
| Total Hard Drive Capacity: | 1 TB |
| Hard Drive Interface: | Serial ATA/300 |
| Hard Drive RPM: | 5400 |
| Hard Drive Configuration: | 1 x 1 TB |
| Optical Drive Type: | DVD-Writer |
| Controllers | |
| Controller Type: | Serial ATA |
| Display & Graphics | |
| Screen Size: | 54.6 cm (21.5") |
| Display Screen Type: | Active Matrix TFT Color LCD |
| Backlight Technology: | LED |
| Screen Mode: | Full HD |
| Screen Resolution: | 1920 x 1080 |
| Aspect Ratio: | 16:9 |
| TV Card: | Yes |
| Digital Tuner: | DVB-T |
| Network & Communication | |
| Ethernet Technology: | Gigabit Ethernet |
| Wireless LAN: | Yes |
| Wireless LAN Standard: | IEEE 802.11b/g/n |
| Modem: | No |
| Input Devices | |
| Keyboard: | Yes |
| Pointing Device Type: | Mouse |
| Built-in Devices | |
| Webcam: | Yes |
| Microphone: | Yes |
| Interfaces/Ports | |
| HDMI: | Yes |
| Total Number of USB Ports: | 6 |
| Number of USB 2.0 Ports: | 4 |
| Number of USB 3.0 Ports: | 2 |
| Network (RJ-45): | Yes |
| Audio Line In: | Yes |
| Audio Line Out: | Yes |
| Modem (RJ-11): | No |
| Software | |
| Operating System Platform: | Windows |
| Operating System: | Windows 7 Home Premium |
| Operating System Architecture: | 64-bit |
| Power Description | |
| Maximum Power Supply Wattage: | 135 W |
| Physical Characteristics | |
| Form Factor: | Desktop |
| Height: | 400 mm |
| Width: | 524 mm |
| Depth: | 113 mm |
| Miscellaneous | |
| Package Contents: |
|
| Certifications & Standards: |
|
Warranty
To see warranty information, enter a valid serial number or SNID first here
