Summary
Want to buy one? Click
◄ [Buy Options]
Need help? Click◄ [Help & Support]
Want to buy service / replacement / upgrade parts? Click◄ [Repair Parts / Upgrades]
Looking for drivers, BIOS utilities or manuals? Click◄ [Downloads]
Need to look up technical specs? Click◄ [Specifications]
Warranty expiry date lookup? Click◄ [Warranty]
Corrupt, damaged or missing operating system (Windows/Linux)? Click◄ [Recovery CD/DVD/USB]
Buy Options
Buy this product from
Buy this product from
Help & Support
Technical Support
In warranty (Limited free support)
• If your device is still under manufacturer's warranty, you are eligible for limited support (free of charge)• Contact your local Packard Bell office
Out of warranty (Premium paid support)
• Warranty expired? You can still get help!• Professional support by Packard Bell trained technicians
• Offered via e-mail or live chat, typical response time is 1-2 hours
• Hardware & software problems
• Upgrades & specifications
• Spare parts search
• Only
• Satisfaction guaranteed, you will only be billed once you approve the answers provided
• Enter your question in the form below to get the process started
Repair Parts / Upgrades
Found 56 parts for NE11HC-428 model (for repairs / spares)
Category | Description | |
|---|---|---|
| AC ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 YELLOW CHICONY CPA09-A065N1, LV5, LOW PROFILE LED LF | |
| AC ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 YELLOW DELTA ADP-65VH BA / LV5 / LOW PROFILE LED LF | |
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 DELTA ADP-65VH DA LF MEET CHINA 5K REGULATION AC ADAPTOR 65W 19V PK10000M540 | |
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 CHICONY POWER A065R035L / A11-065N1A, LV5, LOW PROFILE LF AC ADAPTOR 65W 19V YEL LF CNY ADP 19V 3.42A A065R035L 90~264V STNBSQ, AG19034B082 Made by: Chicony | |
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - LITE-ON 1.7X5.5X11 YELLOW PA-1650-69AW, LV5, LOW PROFILE LED LF AC ADAPTOR 65W 19V 3P YEL LF LEC ADP 19V 3.42A PA-1650-69AW 90~264VSTNBS, 2SZR8AATN10 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SIMPLO ID:AS10D73, FOR HSF 3S2P LGC MAIN COMMON BATTERY LI-ION 6C 4K4 HSF SIM ZAO BATT LI, 934Q2112H 3S2P 4.4A(B)STN BSQ, AHA63222929 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SIMPLO AS10D 3S2P LGC MAIN COMMON ID:AS10D73 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - PANASONIC AS10D51, FOR NEW IC MAX1787 3S2P MAIN COMMON BATTERY LI-ION 6C 4K4mAH PAN GC02001GW10 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SONY AS10D 3S2P MAIN COMMON ID:AS10D41 BATTERY LI-ION 6C 4K4MAH SONY SNY BATT LI,AS10D41 3S2P 4.4A (B) STN BSQ, 2CZYDBTTN10 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SANYO AS10D 3S2P MAIN COMMON NEW IC BQ8055 BATTERY 6C 4K4mAh SANYO GC02001DB10 | |
| BOARD | USB BOARD USB BD P/N: 1HY4ZZZ0076 | |
| BOARD NIC | FOXCONN WIRELSS LAN BROADCOM 4313 IPA 1X1 BGN P/N: 1HYXZZZ104S | |
| BOARD NIC | LITEON WIRELESS LAN ATHEROS HB125 1X1 BGN P/N: 0C05-00FD0PB | |
| BOARD NIC | FOXCONN WIRELSS LAN ATHEROS HB125 1X1 BGN P/N: 1HYXZZZ104R | |
| BOARD NIC | LITEON WIRELESS LAN RELTEK RTL8188CE-VL 1X1 BGN P/N: 1HY4ZZZ009J | |
| CABLE | HDD CONN. CABLE P/N: 1HYXZZZ0975 | |
| CABLE | CABLE FFC USB BOARD TO M/B CABLE FFC USB BOARD TO M/B P/N: 1HY4ZZZ009K | |
| CABLE | LCD CABLE W/ MIC CABLE LCD P/N: 1HY4ZZZ008L | |
| CABLE | CABLE DC-IN FOR 65W CABLE DC-IN 65W P/N: 1HY4ZZZ0079 | |
| CAMERA | CAMERA LITEON HD LT_OV9726_SP 3.5MM WIN8 REV 2.0 P/N: 1HY4ZZZ0173 | |
| CAMERA | CAMERA, CHICONY HD CH_OV9726_AU 3.5MM P/N: 1HY4ZZZ009R | |
| CAMERA | CAMERA, LITEON HD LT_OV9726_SP 3.5MM P/N: 1HY4ZZZ009Q | |
| COVER | LOWER CASE COVER LOWER P/N: 1HY4ZZZ009S | |
| COVER | ODD BEZEL - SUPER MULTI ZQW SUPER-MULTI BEZEL ASSY P/N: 1HY4ZZZ0104 | |
| COVER | UPPER CASE W/TP, TP FFC - SILVER IMR COVER UPPER SILVER IMR W/TP P/N: 1HY4ZZZ0094 | |
| CPU | CPU INTEL CORE I3 I3-2348M PGA 2.3G 35W SANDY BRIDGE 2/4 - SR0TD P/N: KC.234B1.DM8 | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA HLDS GT51N LF W/O BEZEL ZERO POWER SUPPORTED (HF + WINDOWS 7) P/N: GT51N | |
| DVDRW | ODD MODULE SUPERMULTI 12.7MM TRAY DL 8X | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA PANASONIC UJ8C0ADAA1-B LF+HF W/O BEZEL WIN7 | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA PANASONIC UJ8B0AW LF+HF W/O BEZEL (WIN7) | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA PIONEER DVR-TD11RS LF W/O BEZEL 1.01 HF + ZP (HME OPU) | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY 8X SATA HLDS GT51N LF+HF W/O BEZEL 1.01 | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY 8X SATA PANASONIC UJ8E1ADAA1-B LF+HF W/O BEZEL | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY 8X SATA PLDS DS-8A8SH LF+HF W/O BEZEL | |
| HARDWARE | THERMAL MODULE UMA 35W P/N: 1HY4ZZZ0089 | |
| HARDWARE | ODD BRACKET P/N: 1HY4ZZZ0085 | |
| HARDWARE.MISC. | HDD BRACKET COVER BRACKET HDD P/N: 1HYXZZZ0968 | |
| HARDWARE.MISC. | LCD HINGE W/ BRACKET - L COVER LCD HINGE W/ BRACKET-L P/N: 1HY4ZZZ0096 | |
| HARDWARE.MISC. | LCD HINGE W/ BRACKET - R COVER LCD HINGE W/ BRACKET-R P/N: 1HY4ZZZ0095 | |
| HDD | HDD 1TB 5400RPM SATA 2 8MB 2.5" 9.5MM 4K HTS541010A9E680 HGST JAGUAR B,0J26213 LF+HF F/W: DA4863 | |
| HDD | HDD 1TB 5400RPM SATA 2 8MB 2.5" 9.5MM 4K ST1000LM024 SEAGATE HN-M101MBB/ACE, M8, 500G/P SATA 8MB LF+HF F/W:2AR10001 P/N: ST1000LM024 | |
| KEYBOARD | KEYBOARD DARFON TM4T_G11B TM4T INTERNAL 14 STANDARD 89KS BLACK SPANISH Y2010 ACER LEGEND WIN8 P/N: 1KAJZZP001S | |
| KEYBOARD | KEYBOARD CHICONY TM4T_G11B TM4T INTERNAL 14 STANDARD 89KS BLACK SPANISH Y2010 ACER LEGEND P/N: 1KAJZZP0018 | |
| LCD | LCD LED MODULE 14.0" WXGA GLARE W/CCD, ANTENNA*1 PB | |
| LCD | LCD LED 14.0" WXGA GLARE CMI BT140GW01 V6 LF 220NIT 8MS 600:1 LCD LED CMI 14"WXGA GLARE CIX LCD14.0"HD BV LED BT140GW01 V.6 STNBSQ, 27ZQ5LATN50 | |
| LCD | LCD LED 14.0 WXGA GLARE LPL LP140WH4-TLN1 LF 200NIT 16MS 500:1 | |
| LCD | LCD LED 14.0" WXGA GLARE LPL LP140WH4-TLC1 LF 220NIT 16MS | |
| LCD | LCD LED 14.0" WXGA GLARE AUO B140XW01 V8 0A LF 220NIT 8MS 500:1 (POWER SAVING) | |
| LCD | LCD LED MODULE 14.0" WXGA GLARE, ANTENNA*1 PB W/ CCD LED LIGHT | |
| MAINBOARD | MAIN BOARD HM77 UMA W/RTC BATT,CPU BKT, W/O CPU,RAM P/N: 11MBZZZ0105 | |
| PLASTIC | DUMMY CARD P/N: 1HY4ZZZ0082 | |
| PLASTIC | BASE DOOR P/N: 1HY4ZZZ009T | |
| PLASTIC | LCD BEZEL (W/ LED) PB P/N: 1HY4ZZZ010E | |
| PLASTIC | LCD BEZEL (W/O LED) PB P/N: 1HY4ZZZ0107 | |
| PLASTIC | LCD COVER W/ANT*1 BLACK IMR PB P/N: 1HY4ZZZ0105 | |
| SPEAKER | SPEAKER SET W/R,L SPEAKER SET R&L P/N: 1HY4ZZZ008D |
Downloads
Specifications
| Model P/N: | NX.C1AAL.001 / NXC1AAL001 |
| Release date (year): | 2013 |
| Quick specs: | ENNE11HC-428-CL W8SL64B13/I3-2348M/8G/1TB/6L2.2/14.0 ENNE11HC-32348G1TMnks W8SL64B13CL3 UMACks_3 2*4G/1000/6L2.2/5R/CB_GN_HD_Rk_ESN1 |
| Processor & Chipset | |
|---|---|
| Processor Manufacturer: | Intel |
| Processor Type: | Core i3 |
| Processor Generation: | 2nd Gen |
| Processor Model: | i3-2348M |
| Processor Speed: | 2.30 GHz |
| Processor Core: | Dual-core (2 Core) |
| Cache: | 3 MB |
| Direct Media Interface: | 5 GT/s |
| 64-bit Processing: | Yes |
| Hyper-Threading: | Yes |
| Chipset Manufacturer: | Intel |
| Chipset Model: | HM77 Express |
| Memory | |
| Standard Memory: | 8 GB |
| Maximum Memory: | 8 GB |
| Memory Technology: | DDR3 SDRAM |
| Number of Total Memory Slots: | 2 |
| Memory Card Reader: | Yes |
| Memory Card Supported: | Memory Stick |
| Storage | |
| Hard Drive Capacity: | 1 TB |
| Hard Drive Interface: | Serial ATA |
| Hard Drive RPM: | 5400 |
| Optical Drive Type: | DVD-Writer |
| Display & Graphics | |
| Screen Size: | 35.6 cm (14") |
| Display Screen Type: | LCD |
| Aspect Ratio: | 16:9 |
| Screen Mode: | HD |
| Screen Resolution: | 1366 x 768 |
| Backlight Technology: | LED |
| HDCP Supported: | Yes |
| Graphics Controller Manufacturer: | Intel |
| Graphics Controller Model: | HD 3000 |
| Graphics Memory Technology: | DDR3 SDRAM |
| Graphics Memory Accessibility: | Shared |
| TV Card: | No |
| Network & Communication | |
| Wireless LAN: | Yes |
| Wireless LAN Manufacturer: | Atheros |
| Wireless LAN Model: | HB125 |
| Wireless LAN Standard: | IEEE 802.11b/g/n |
| Ethernet Technology: | Gigabit Ethernet |
| Bluetooth: | No |
| Built-in Devices | |
| Front Camera/Webcam: | Yes |
| Microphone: | Yes |
| Finger Print Reader: | No |
| Speakers: | Yes |
| Interfaces/Ports | |
| HDMI: | Yes |
| Total Number of USB Ports: | 3 |
| Number of USB 2.0 Ports: | 3 |
| VGA: | Yes |
| Network (RJ-45): | Yes |
| Audio Line In: | Yes |
| Audio Line Out: | Yes |
| Software | |
| Operating System Platform: | Windows |
| Operating System: | Windows 8 |
| Operating System Architecture: | 64-bit |
| Input Devices | |
| Keyboard: | Yes |
| Pointing Device Type: | TouchPad |
| TouchPad Features: | Multi-touch Gesture |
| Battery Information | |
| Number of Cells: | 6-cell |
| Battery Chemistry: | Lithium Ion (Li-Ion) |
| Battery Capacity: | 4400 mAh |
| Battery Energy: | 48 Wh |
| Maximum Battery Run Time: | 4 Hour |
| Power Description | |
| Maximum Power Supply Wattage: | 65 W |
| Physical Characteristics | |
| Height: | 33.2 mm |
| Width: | 381.6 mm |
| Depth: | 253 mm |
| Weight (Approximate): | 2.60 kg |
| Miscellaneous | |
| Package Contents: |
|
| Additional Information: | Wireless LAN: Acer Nplify 802.11b/g/n |
| Certifications & Standards: | ACPI 3.0 |
| Security Features: |
|
Warranty
To see warranty information, enter a valid serial number or SNID first here
