- Summary
- Buy Options
- Help & Support
- Repair Parts / Upgrades
- Downloads
- Specifications
- Warranty
Want to buy one? Click
◄ [Buy Options]
Need help? Click◄ [Help & Support]
Want to buy service / replacement / upgrade parts? Click◄ [Repair Parts / Upgrades]
Looking for drivers, BIOS utilities or manuals? Click◄ [Downloads]
Need to look up technical specs? Click◄ [Specifications]
Warranty expiry date lookup? Click◄ [Warranty]
Corrupt, damaged or missing operating system (Windows/Linux)? Click◄ [Recovery CD/DVD/USB]
Buy this product from
Buy this product from
Technical Support
In warranty (Limited free support)
• If your device is still under manufacturer's warranty, you are eligible for limited support (free of charge)• Contact your local Gateway office
Out of warranty (Premium paid support)
• Warranty expired? You can still get help!• Professional support by Gateway trained technicians
• Offered via e-mail or live chat, typical response time is 1-2 hours
• Hardware & software problems
• Upgrades & specifications
• Spare parts search
• Only
• Satisfaction guaranteed, you will only be billed once you approve the answers provided
• Enter your question in the form below to get the process started
Found 43 parts for ZX4665-UR11 model (for repairs / spares)
| Category | Description | AC ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW-TIP - 1.7X5.5X11 LITE-ON PA-1650-86AW LF MEET CHINA 5KM | ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 CHICONY POWER A065R035L / A11-065N1A, LV5, LOW PROFILE LF AC ADAPTOR 65W 19V YEL LF CNY ADP 19V 3.42A A065R035L 90~264V STNBSQ, AG19034B082 Made by: Chicony | ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW -TIP 1.7X5.5X11 - CHICONY A065R035L-AC01-03 LF MEET CHINA 5KM AC ADAPTOR 65W 19V YEL LF ADP 65W 19V A065R035L-AC01-03 APISA2 | BOARD NIC | LITE-ON WCBN611AH WLAN 1T1R COMBO W/ 2A CONNECTOR, WCBN612AH-AA(2A),ATHEROS WB335,WLAN 1T1R COMBO W/ 2A CONNECTOR P/N: 0C08-00BU0PB | BOARD OTHER | FRONT I/O BOARD W/CARD READER | BOARD OTHER | BOARD CONVERTER FOR 19.5" CMI 200NIT | CABLE | WIRELESS ANTENNA AUX WLAN | CABLE | WIRELESS ANTENNA MAIN WLAN | CABLE | LVDS CABLE | CABLE | CONVERTER BOARD TO MAINBOARD CABLE | CABLE | CONVERTER BOARD TO PANEL CABLE FOR CMI | CABLE | POWER CORD 10A 125V US P/N: 27.01518.311 | CABLE | HDD SATA CABLE | CABLE | POWER CORD 10A 125V US | CABLE | ODD SATA CABLE | CABLE | FIO USB3.0 CABLE | CABLE | WEBCAM CABLE | CAMERA | CAMERA 1.0M_HD 1MIC | DVDRW | ODD SUPER-MULTI 08X SATA 09.0MM TRAY GUA0N HLDS RW LF+HF W/O BEZEL SATA M-DISC | FAN/HEAT SINK | FAN 9020 3900RPM SUNON APISA | HARDWARE | HDD BRACKET | HARDWARE | ASSEMBLY THERMAL MODULE FOR UMA | HARDWARE | MAINBOARD SHIELDING | HARDWARE | MAIN BRACKET | HARDWARE | FRONT I/O BRACKET | HARDWARE | ODD BRACKET | HARDWARE | SUPPORT FAN & HINGE FUNCTION BRACKET | HDD | HDD 500GB 7200RPM SATA 3 16MB 3.5" 4K ST500DM002 SEAGATE (PHARAOH 4K) LF F/W:KC45 P/N: HDS721050CLA662 | KEYBOARD | KEYBOARD PRIMAX PR1101U USB BLACK US WITH GATEWAY LOGO WITH WIN8 SYMBOL | LCD | LED LCD CMI 19.5W HD+ NONE GLARE M195FGE-L23 C1 LF 200NIT 5MS 1000:1 | MAINBOARD | IC CPU IVY BRIDGE 1017U 2C 1.6GHZ 2MB BG | MAINBOARD | MAINBOARD ZX4665 INTEL HM70 RTL8111FA ACER LOGO PROPRIETARY V1.0 LF CELERON1017U | MOUSE / TOUCHPAD | LOGITECH USB MOUSE M-U0037-O WITH GATEWAY LOGO | MOUSE / TOUCHPAD | PRIMAX USB MOUSE MOANUOA WITH GATEWAY LOGO | ODD | ODD DVD/RW SUPER-MULTI DRIVE 9.0MM TRAY 8X SATA M-DISC PANASONIC UJ8E2QBAA2-B LF+HF W/O BEZEL DVD/R/RW SMULTI 9MM TRAY 8X MAT DVD+ / - RW UJ8E2QBAA2-B STN BSQB, 24ZYWCDTN00 Made by: Panasonic | ODD | ODD DVD/RW SUPER-MULTI DRIVE 9.0MM TRAY 8X SATA PANASONIC UJ8D2QBAA2-B LF W/O BEZEL DVD/R/RW SMULTI 9MM TRAY 8X ODD DVD-RW 9.0 TL UJ8D2QBAA2-B | PLASTIC | ODD BEZEL BLACK PISA 19.5L | PLASTIC | REAR COVER 19.5" W/FOOT RUBBER BLACK | PLASTIC | HINGE MODULE BLACK W/GATEWAY LOGO | PLASTIC | FRONT BEZEL ASSY 19.5" BLACK W/POWER BUTTON CABLE & GATEWAY LOGO | PLASTIC | WEBCAM HOLDER | PLASTIC | HINGE COVER BLACK PISA 19.5L | SPEAKER | NORMAL SPEAKER |
|---|
Click here to download:
• Drivers / Applications
• User Guides / Manuals
• BIOS / UEFI / Firmware
Note: opens in a new tab / window
| Model P/N: | DQ.GEWAA.002 / DQGEWAA002 |
| Release date (year): | 2014 |
| Quick specs: | ZX4665-UR11 W81ML64A/1017U/4G/500GB/19.5 ZX4665_Wbn1017U_65W_CR PA CH W81ML64aAAC51/CM1017UB/4G*1/500G_4K*1/NSM8XS9.0/DLED19.5H/802.11 b/g/n/mPCIe/1T1R+BT Kit for 2A AIO/USBPro1_GW/USB_black_common_GW/. |
| Processor & Chipset | |
|---|---|
| Number of Processors Supported: | 1 |
| Number of Processors Installed: | 1 |
| Processor Manufacturer: | Intel |
| Processor Type: | Celeron |
| Processor Model: | 1017U |
| Processor Speed: | 1.60 GHz |
| Cache: | 2 MB |
| Direct Media Interface: | 5 GT/s |
| 64-bit Processing: | Yes |
| Chipset Manufacturer: | Intel |
| Chipset Model: | HM70 |
| Memory | |
| Standard Memory: | 4 GB |
| Maximum Memory: | 4 GB |
| Memory Technology: | DDR3 SDRAM |
| Memory Card Reader: | Yes |
| Storage | |
| Number of Hard Drives: | 1 |
| Total Hard Drive Capacity: | 500 GB |
| Hard Drive Interface: | Serial ATA/300 |
| Hard Drive RPM: | 7200 |
| Hard Drive Configuration: | 1 x 500 GB |
| Optical Drive Type: | DVD-Writer |
| Display & Graphics | |
| Screen Size: | 19.5" |
| Display Screen Type: | Active Matrix TFT Color LCD |
| Backlight Technology: | LED |
| Screen Mode: | HD+ |
| Screen Resolution: | 1600 x 900 |
| Aspect Ratio: | 16:9 |
| Touchscreen: | No |
| TV Card: | No |
| Network & Communication | |
| Ethernet Technology: | Gigabit Ethernet |
| Wireless LAN: | Yes |
| Wireless LAN Standard: | IEEE 802.11b/g/n |
| Bluetooth: | Yes |
| Modem: | No |
| Input Devices | |
| Keyboard: | Yes |
| Pointing Device Type: | Mouse |
| Built-in Devices | |
| Webcam: | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports: | 3 |
| Number of USB 2.0 Ports: | 2 |
| Number of USB 3.0 Ports: | 1 |
| Network (RJ-45): | Yes |
| Audio Line In: | Yes |
| Audio Line Out: | Yes |
| Modem (RJ-11): | No |
| Software | |
| Operating System Platform: | Windows |
| Operating System: | Windows 8.1 |
| Operating System Architecture: | 64-bit |
| Power Description | |
| Maximum Power Supply Wattage: | 65 W |
| Physical Characteristics | |
| Form Factor: | Desktop |
| Height: | 19.1" |
| Width: | 13.2" |
| Depth: | 3.7" |
| Weight (Approximate): | 20 lb |
| Miscellaneous | |
| Package Contents: |
|
| Certifications & Standards: |
|
To see warranty information, enter a valid serial number or SNID first here
