Summary
Want to buy one? Click
◄ [Buy Options]
Need help? Click◄ [Help & Support]
Want to buy service / replacement / upgrade parts? Click◄ [Repair Parts / Upgrades]
Looking for drivers, BIOS utilities or manuals? Click◄ [Downloads]
Need to look up technical specs? Click◄ [Specifications]
Warranty expiry date lookup? Click◄ [Warranty]
Corrupt, damaged or missing operating system (Windows/Linux)? Click◄ [Recovery CD/DVD/USB]
Buy Options
Help & Support
Technical Support
In warranty (Limited free support)
• If your device is still under manufacturer's warranty, you are eligible for limited support (free of charge)• Contact your local Gateway office
Out of warranty (Premium paid support)
• Warranty expired? You can still get help!• Professional support by Gateway trained technicians
• Offered via e-mail or live chat, typical response time is 1-2 hours
• Hardware & software problems
• Upgrades & specifications
• Spare parts search
• Only
• Satisfaction guaranteed, you will only be billed once you approve the answers provided
• Enter your question in the form below to get the process started
Repair Parts / Upgrades
Found 26 parts for SX2870-UR10P model (for repairs / spares)
Category | Description | |
---|---|---|
BOARD NIC | LITE-ON WN7601R (LOW-PROFILE) 802.11 B/G/N (PCI-E) WN7601R, RALINK RT3090, 802.11B/G/N 1X1 WLAN PCI-E X1 CARD (LOW-PROFILE) W/ ANTENNA | |
BOARD OTHER | FIO+MCR MODULE( MINGJI) - MEMORY CARD READER MODULE P/N: 1A22YFP01-000 | |
CABLE | POWER SW & LED(WHITE/(5.0) HDD LED (WHITE /(3.0) CABLE,L=250 /230MM CABLE DOUBLE SHIELDING(HSQ) P/N: 35101GE03-000 | |
CABLE | POWER SW & LED(WHITE/F5.0) HDD LED (WHITE/F3.0) CABLE P/N: 35101GE00-000 | |
CABLE | SATA HDD DATA CABLE 400MM(TIANXUN) P/N: 350909W01-000 | |
CABLE | SATA HDD DATA CABLE 400MM CABLE DATA HDD SATA 400MM P/N: 350909W00-000 | |
CABLE | POWER CORD US 1.83M 200-8401 HONGLIN R P/N: 5Q062-027-GP | |
CABLE | POWER CORD US 300V 1.8M E237464 GRANDSUN R P/N: 5Q062-026-GP | |
CABLE | POWER CORD US 125V 10A 1.8M IS R P/N: 5Q062-001-GP | |
CABLE | POWER CORD US 125V 10A 1.8M TX R P/N: 5Q062-021-GP | |
CABLE | ODD SATA(MINGJI) P/N: 35100SD00-000 | |
CHASSIS | HX097K_GX170: GTW 8.5L L3 CHASSIS ASSY P/N: 1A322VG00-600 | |
CPU | CPU INTEL CORE I3 2120 LGA 3M 1333 1155 65W 3.3G, DUAL CORE P/N: SR05Y | |
DVDRW | ODD SUPER-MULTI 16X SATA GH70N HLDS LF+HF BLACK BEZEL HH (WIN7) P/N: GH70N | |
DVDRW | ODD SUPER-MULTI 16X SATA DVR-219RS PIONEER BLACK BEZEL LF HH DL (WIN7+HF) P/N: DVR-219RS | |
HARDWARE | LEFT PANEL(PAINT) P/N: 1A3234200-600 | |
HDD | HDD 1TB 7200RPM SATA 3 64MB 3.5" 4K ST1000DM003 SEAGATE LF F/W:CC4B P/N: ST1000DM003 | |
KEYBOARD | KEYBOARD LITE-ON SK-9020 USB 104KS BLACK US | |
MAINBOARD | MB KIT GLENA INTEL B75 ACER LOGO W/O 1394 LF | |
MOUSE / TOUCHPAD | PRIMAX OPTICAL MOUSE USB MOFFUO WITH POLISH COVER P/N: 82-225-012310 | |
MOUSE / TOUCHPAD | LOGITECH OPTICAL MOUSE USB M-U0027-O WITH POLISH COVER P/N: 82-225-002485 | |
PLASTIC | GX170 TOP-COVER ASSY P/N: 1A3230100-600 | |
PLASTIC | GX170 FRONT BEZEL ASSY P/N: 1A322VJ00-600 | |
SPS | PSU CHICONY POWER CPB09-D220R 220W NONE PFC 2 100-127/220-240V POWER SUPPLY 220W PFC PSU 220NPFC(8.5L) CPB09-D220R EuP CP R | |
SPS | PSU LITE-ON PS-5221-06A2 220W NONE PFC 100-127/220-240V (20 - 24 PIN PWR CONN) POWER SUPPLY 220W PFC SPS NON-PFC 220W (8.5L) EUP PS-5221-06A2 | |
SPS | PSU DELTA DPS-220UB-3A 220W NONE PFC 100-127/220-240V POWER SUPPLY 220W EUP PFC SPS 220W EUP 115VAC/230V NPFC EUP DPS-22 |
Downloads
Specifications
Model P/N: | DT.GD2AA.001 / DTGD2AA001 |
Release date (year): | 2012 |
Quick specs: | SX2870-UR10P W7HP64G/I3-2120/6G/1TB SX2870_H CH PA001 W7HP64gAAC6/Ci3-2120/4G*1+2G*1/1000G_4K*1/DSM16XS/802.11bgn/USB/Godiva/USB/P5 |
Processor & Chipset | |
---|---|
Number of Processors Supported: | 1 |
Number of Processors Installed: | 1 |
Processor Manufacturer: | Intel |
Processor Type: | Core i3 |
Processor Generation: | 2nd Gen |
Processor Model: | i3-2120 |
Processor Core: | Dual-core (2 Core) |
Processor Speed: | 3.30 GHz |
Cache: | 3 MB |
Direct Media Interface: | 5 GT/s |
64-bit Processing: | Yes |
Hyper-Threading: | Yes |
Chipset Manufacturer: | Intel |
Chipset Model: | B75 Express |
Memory | |
Standard Memory: | 6 GB |
Maximum Memory: | 16 GB |
Memory Technology: | DDR3 SDRAM |
Memory Standard: | DDR3-1333/PC3-10600 |
Number of Total Memory Slots: | 4 |
Memory Card Reader: | Yes |
Storage | |
Number of Hard Drives: | 1 |
Total Hard Drive Capacity: | 1 TB |
Hard Drive Interface: | Serial ATA/300 |
Hard Drive RPM: | 7200 |
Hard Drive Configuration: | 1 x 1 TB |
Optical Drive Type: | DVD-Writer |
Controllers | |
Controller Type: | Serial ATA |
Display & Graphics | |
TV Card: | No |
Network & Communication | |
Ethernet Technology: | Gigabit Ethernet |
Wireless LAN: | Yes |
Wireless LAN Standard: | IEEE 802.11b/g/n |
Modem: | No |
I/O Expansions | |
Number of Total Expansion Bays: | 2 |
Number of External 5.25" Bays: | 1 |
Number of 3.5" Bays: | 1 |
Number of Total Expansion Slots: | 2 |
Number of PCI Express x1 Slots: | 1 |
Number of PCI Express x16 Slots: | 1 |
Input Devices | |
Keyboard: | Yes |
Pointing Device Type: | Mouse |
Interfaces/Ports | |
HDMI: | Yes |
Total Number of USB Ports: | 8 |
Number of USB 2.0 Ports: | 6 |
Number of USB 3.0 Ports: | 2 |
Network (RJ-45): | Yes |
Audio Line In: | Yes |
Audio Line Out: | Yes |
VGA: | Yes |
Modem (RJ-11): | No |
Software | |
Operating System Platform: | Windows |
Operating System: | Windows 7 Home Premium |
Operating System Architecture: | 64-bit |
Power Description | |
Maximum Power Supply Wattage: | 220 W |
Physical Characteristics | |
Form Factor: | Small Form Factor |
Height: | 10.4" |
Width: | 3.9" |
Depth: | 14.9" |
Miscellaneous | |
Package Contents: |
|
Certifications & Standards: |
|
