Repair Parts / Upgrades
Found 66 parts for NV55C15e model (for repairs / spares)
Category | Description | |
|---|---|---|
| AC ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 YELLOW CHICONY CPA09-A065N1, LV5, LOW PROFILE LED LF | |
| AC ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - LITE ON 1.7X5.5X11 YELLOW PA0650-22AC LV5 LED LF | |
| AC ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 YELLOW DELTA ADP-65VH BA / LV5 / LOW PROFILE LED LF | |
| AC ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 YELLOW DELTA ADP-65JH DB A / LV5 LED LF P/N: 870104P00-065 | |
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - HIPRO 1.7X5.5X11 HP-A0652R3B 1LF, LV5 LED LF AC ADAPTER HIPRO 65W 19V TR85/86/87 AC ADAP HIPR HP-A0652R3B 1LF 65W 3P ABO!, PK10000FG30 | |
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - LITE-ON 1.7X5.5X11 YELLOW PA-1650-69AW, LV5, LOW PROFILE LED LF AC ADAPTOR 65W 19V 3P YEL LF LEC ADP 19V 3.42A PA-1650-69AW 90~264VSTNBS, 2SZR8AATN10 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SIMPLO AS10D 3S2P SAMSUNG MAIN COMMON ID:AS10D BATTERY LI-ION 6C 4K4MAH SIM BTY PACK LI+ SDI 6C 2.2AH SMP | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SIMPLO AS10D 3S2P LGC MAIN COMMON ID:AS10D73 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SIMPLO AS10D 3S2P PANASONIC MAIN COMMON ID:AS10D71 BATTERY LI-ION 6C 4K4MAH SIM BTY PACK LI+ PANA 6C 2.2AH SMP | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SAMSUNG AS10D 3S2P MAIN COMMON ID:AS10D61 BATTERY LI-ION 6C 4K4MAH SAM BTY PACK LI+ SDI 6C 2.2AH SDI | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - PANASONIC AS10D 3S2P MAIN COMMON ID:AS10D51 BATTERY LI-ION 6C 4K4MAH PAN BATT PA PA 3S2P 4.4AH 7 0C9 ABO !, GC020016I10 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SONY AS10D 3S2P MAIN COMMON ID:AS10D41 BATTERY LI-ION 6C 4K4MAH SONY SNY BATT LI,AS10D41 3S2P 4.4A (B) STN BSQ, 2CZYDBTTN10 | |
| BATTERY | BATTERY 6-CELL LI-ION 4400MAH - SANYO AS10D 3S2P MAIN COMMON ID:AS10D31 BATTERY LI-ION 6C 4K4MAH SAN BATT SA SA 3S2P 4.4AH 7 0C9 ABO !, GC020016G10 | |
| BLUETOOTH | BLUETOOTH BOARD FOXCONN ATH T77H222.01 S.P BU12 V3.0 6PIN CONN; BT 3.0, USE WITH WLAN ATHEROS; BT CABLE 50.PUMN7.001 MODULE BLUETOOTH BT MODULE ATHEROS AR3011 BU12 BT2.1/3.0, 56.25032.081 P/N: 1HYXZZZ093G | |
| BOARD BLUETOOTH | FOXCONN BLUETOOTH ATH AR3011 (BT3.0) (USE WITH BLUETOOTH CABLE 8-PIN & WITH WIRELESS LAN ATHEROS) P/N: 1HYXZZZ070E | |
| BOARD BLUETOOTH | FOXCONN BLUETOOTH BRM 2046 BT3.0 (T60H928.33) F/W:861(USE WITH BLUETOOTH CABLE 8-PIN) P/N: 71GF05BO001 | |
| BOARD BLUETOOTH | FOXCONN BLUETOOTH BRM 2070 (T77H114.01) BT 3.0 (USE WITH BLUETOOTH CABLE-6PIN, 50.BN707.001); USE WITH WLAN BROADCOMM
P/N: 1HYXZZZ0849 | |
| BOARD NIC | LITEON WIRELESS LAN ATHERIS HB97 2X2 BGN (HM) WN6603AH (T77H167.07) P/N: 6042B0143701 | |
| BOARD NIC | WIRELESS LAN FOXCONN ATHEROS HB97 2X2 (HM); ZQ2 W/L MINICARD 802.11BGN(T77H167.07)S.P P/N: 1HYXZZZ078G | |
| BOARD NIC | LITEON WIRELESS LAN REALTEK 8192SE BGN WN6603LH(2X2 BGN) P/N: 71FY03BO003 | |
| BOARD OTHER | WIRELESS LAN BROADCOM, LITEON, 43225 2X2 BGN P/N: 71GE02BO010 | |
| BOARD OTHER | ODD BOARD-UMA P/N: 71GS08BO001 | |
| BOARD OTHER | USB BOARD-UMA P/N: 71GS07BO001 | |
| BOARD OTHER | POWER BOARD-UMA P/N: 71GS05BO001 | |
| CABLE | ANTENNA WLAN-MAIN P/N: 71GS23BO001 | |
| CABLE | CABLE DC-IN 65W (YELLOW TIP) CABLE DC-IN 65W P/N: 71GS12BO001 | |
| CABLE | CABLE TP FFC P/N: 71GS11BO001 | |
| CABLE | BLUE TOOTH CABLE-6PIN CABLE BLUETOOTH 6P P/N: 71GS10BO002 | |
| CABLE | BLUE TOOTH CABLE-8PIN CABLE BLUETOOTH 8P P/N: 71GS10BO001 | |
| CABLE | LED CABLE FOR W/CMOS CABLE LED W/CMOS P/N: 71GS25BO001 | |
| CABLE | ANTENNA WLAN-AUX P/N: 71GS23BO002 | |
| CABLE | POWER CORD US 3 PIN P/N: 71B304BO014 | |
| CAMERA | CAMERA 1.3M P/N: 71GS28BO001 | |
| COVER | LOWER CASE-UMA COVER LOWER UMA P/N: 71GS14BO001 | |
| CPU | CPU INTEL CORE I5 460M PGA 2.53G 35W K-0 P/N: SLBZW | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA DS-8A5SH LF+HF W/O BEZEL SATA WITH TI + ROHM SOLUTION (HF + WINDOWS 7) P/N: DS-8A5SH | |
| DVDRW | ODD DVD/RW SATA 8X SUPER-MULTI DRIVE 12.7MM TRAY DL 8X DS-8A4SH LF W/O BEZEL SATA (HF + WINDOWS 7) P/N: DS-8A4SH | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA AD-7585H LF W/O BEZEL (HF + WINDOWS 7) P/N: AD-7585H | |
| DVDRW | ODD DVD/RW SUPER-MULTI DRIVE 12.7MM TRAY DL 8X SATA GT32N (R5-2) LF W/O BEZEL WITH RENESAS SOLUTION + PCC LD (HF + WINDOWS 7) P/N: GT32N | |
| DVDRW | ODD SUPER-MULTI 08X SATA 12.70MM TRAY GT30N HLDS LF DL W/O BEZEL (HF + WINDOWS 7) P/N: GT30N | |
| DVDRW | ODD BD COMBO MODULE | |
| HARDWARE | THERMAL MODULE-UMA W/O FAN P/N: 71GS02BO021 | |
| HARDWARE | ODD BRACKET P/N: 71GS18BO001 | |
| HARDWARE | HDD CARRIER-UMA P/N: 71GS17BO001 | |
| HARDWARE.COOLING | FAN-UMA FAN UMA P/N: 71GS03BO021 | |
| HARDWARE.MISC. | LED BRACKET R&L COVER BRACKET LED R L P/N: 71GS27BO001 | |
| HDD | HDD 500GB 5400RPM SATA 2 8MB 2.5" 9.5MM WD5000BEVT WD F/W:01.01A01 P/N: WD5000BEVT | |
| HDD | HDD 500GB 5400RPM SATA 2 8MB 2.5" 9.5MM HTS545050B9A300 HGST PANTHER B LF F/W:C60F DISK IMBALANCE CRITERIA = 0.014G-CM, HGST PN - 0A74425 P/N: HTS545050B9A300 | |
| HDD | HDD 500GB 5400RPM SATA 2 8MB 2.5" MK5065GSX TOSHIBA LF F/W:GJ002J P/N: MK5065GSX | |
| HDD | HDD 500GB 5400RPM SATA 2 8MB 2.5" 9.5MM 4K ST9500325AS SEAGATE LF F/W:0001SDM1 P/N: ST9500325AS | |
| KEYBOARD | KEYBOARD GATEWAY AC7T_G10B AC7T INTERNAL 17 STANDARD 104KS BLACK SPANISH TEXTURE P/N: 71FY07BO018 | |
| LCD | LCD LED 15.6" WXGA GLARE AUO B156XW02 V2 LF 200NIT 8MS 500:1 (POWER SAVING) | |
| LCD | LCD LED 15.6" WXGA GLARE BOE HT156WXB-500 LF 220NIT 8MS 500:1 | |
| LCD | LCD LED 15.6" WXGA GLARE CMO N156B6-L0B LF 220NIT 8MS 650:1 | |
| LCD | LCD LED 15.6" WXGA GLARE CPT CLAA156WB11A LF 220NIT 8MS 600:1 | |
| LCD | LCD LED MODULE 15.6" WXGA GLARE W/ANTENNA*2, CCD 1.3M, RED - GTW | |
| LCD | LCD LED 15.6" WXGA GLARE LPL LP156WH2-TLEA LF 220NIT 16MS 500:1 (COLOR ENGINE) | |
| LCD | LCD LED 15.6" WXGA GLARE SAMSUNG LTN156AT02-A04 LF 220NIT 8MS 500:1 | |
| MAINBOARD | MAINBOARD AS5742 INTEL HM55 LF P/N: 71GS01BO021 | |
| MICROPHONE | MIC SET-UMA P/N: 71GS30BO001 | |
| PLASTIC | LCD BEZEL FOR W/CMOS GW P/N: 71GT05BO002 | |
| PLASTIC | UPPER CASE ASSY, INCL.TP - UMA - RED P/N: 71GT02BO003 | |
| PLASTIC | ODD BEZEL-SM P/N: 71GS19BO001 | |
| PLASTIC | UNILOAD DOOR-UMA P/N: 71GS15BO001 | |
| PLASTIC | LED LCD COVER-RED GW P/N: 71GT04BO004 | |
| SPEAKER | SPEAKER L P/N: 71GS31BO001 |
Downloads
Specifications
| Model P/N: | LX.WSX02.019 / LXWSX02019 |
| Release date (year): | 2011 |
| Quick specs: | NV55C15E-ES W7HP64EM/I5460M/4G/500GB/BT/6L2.2 NV55C15e EM W7HP64EMWSEA1 UMACrr_3 2*2G/500_L/BT/6L2.2/2R/CB_bgn_1.3C_AUr_ES31 |
| Processor & Chipset | |
|---|---|
| Processor Manufacturer: | Intel |
| Processor Type: | Core i5 |
| Processor Generation: | 1st Gen |
| Processor Model: | i5-460M |
| Processor Speed: | 2.53 GHz |
| Processor Core: | Dual-core (2 Core) |
| Cache: | 3 MB |
| Direct Media Interface: | 2.50 GT/s |
| 64-bit Processing: | Yes |
| Hyper-Threading: | Yes |
| Chipset Manufacturer: | Intel |
| Chipset Model: | HM55 Express |
| Memory | |
| Standard Memory: | 4 GB |
| Maximum Memory: | 8 GB |
| Memory Technology: | DDR3 SDRAM |
| Memory Standard: | DDR3-1066/PC3-8500 |
| Number of Total Memory Slots: | 2 |
| Memory Card Reader: | Yes |
| Memory Card Supported: | SD |
| Storage | |
| Hard Drive Capacity: | 500 GB |
| Hard Drive Interface: | Serial ATA |
| Hard Drive RPM: | 5400 |
| Optical Drive Type: | DVD-Writer |
| Display & Graphics | |
| Screen Size: | 39.6 cm (15.6") |
| Display Screen Type: | LCD |
| Display Screen Technology: | UltraBright |
| Aspect Ratio: | 16:9 |
| Screen Mode: | WXGA |
| Screen Resolution: | 1366 x 768 |
| HDCP Supported: | Yes |
| TV Card: | No |
| Network & Communication | |
| Wireless LAN: | Yes |
| Wireless LAN Standard: | IEEE 802.11b/g/n |
| Ethernet Technology: | Gigabit Ethernet |
| Bluetooth: | Yes |
| Bluetooth Standard: | Bluetooth 3.0 |
| Built-in Devices | |
| Front Camera/Webcam: | Yes |
| Microphone: | Yes |
| Finger Print Reader: | No |
| Speakers: | Yes |
| Interfaces/Ports | |
| HDMI: | Yes |
| Total Number of USB Ports: | 3 |
| Number of USB 2.0 Ports: | 3 |
| VGA: | Yes |
| Audio Line In: | Yes |
| Audio Line Out: | Yes |
| Software | |
| Operating System Platform: | Windows |
| Operating System: | Windows 7 Home Premium |
| Operating System Architecture: | 64-bit |
| Input Devices | |
| Keyboard: | Yes |
| Pointing Device Type: | TouchPad |
| TouchPad Features: | Multi-gesture touchpad |
| Battery Information | |
| Number of Cells: | 6-cell |
| Battery Chemistry: | Lithium Ion (Li-Ion) |
| Battery Capacity: | 4400 mAh |
| Power Description | |
| Maximum Power Supply Wattage: | 65 W |
| Physical Characteristics | |
| Color: | Red |
| Height (Front): | 31 mm |
| Height (Rear): | 34.14 mm |
| Height: | 34.1 mm |
| Width: | 381 mm |
| Depth: | 253 mm |
| Weight (Approximate): | 2.60 kg |
| Miscellaneous | |
| Package Contents: |
|
| Additional Information: | Wireless LAN: Acer Nplify 802.11b/g/n |
| Certifications & Standards: | ACPI 3.0 |
