Summary
Want to buy one? Click
◄ [Buy Options]
Need help? Click◄ [Help & Support]
Want to buy service / replacement / upgrade parts? Click◄ [Repair Parts / Upgrades]
Looking for drivers, BIOS utilities or manuals? Click◄ [Downloads]
Need to look up technical specs? Click◄ [Specifications]
Warranty expiry date lookup? Click◄ [Warranty]
Corrupt, damaged or missing operating system (Windows/Linux)? Click◄ [Recovery CD/DVD/USB]
Buy Options
Buy this product from
Buy this product from
Help & Support
Technical Support
In warranty (Limited free support)
• If your device is still under manufacturer's warranty, you are eligible for limited support (free of charge)• Contact your local Gateway office
Out of warranty (Premium paid support)
• Warranty expired? You can still get help!• Professional support by Gateway trained technicians
• Offered via e-mail or live chat, typical response time is 1-2 hours
• Hardware & software problems
• Upgrades & specifications
• Spare parts search
• Only
• Satisfaction guaranteed, you will only be billed once you approve the answers provided
• Enter your question in the form below to get the process started
Repair Parts / Upgrades
Found 46 parts for NE52203M model (for repairs / spares)
Category | Description | |
|---|---|---|
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 PA-1650-86AW, LV5, LOW PROFILE LF AC ADAPTER 65W LF LITEON ADP 65W 19V YELLOW LITE-ON PA-1650-86AW | |
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 DELTA ADP-65VH DA LF MEET CHINA 5K REGULATION AC ADAPTOR 65W 19V PK10000M540 | |
| ADAPTER | ADAPTER 65W 19V 3-PIN YELLOW TIP - 1.7X5.5X11 CHICONY POWER A065R035L / A11-065N1A, LV5, LOW PROFILE LF AC ADAPTOR 65W 19V YEL LF CNY ADP 19V 3.42A A065R035L 90~264V STNBSQ, AG19034B082 Made by: Chicony | |
| BATTERY | BATTERY 4-CELL LI-ION 2500MAH - SANYO AL12A32 4S1P MAIN COMMON (TISI + PSE LOGO) BATTERY SANYO AL12A32 LI-ION 4 BTY PACK LI+ SANYO 4C 2.5AH SANYO Made by: Sanyo | |
| BATTERY | BATTERY 4-CELL LI-ION 2500MAH SIMPLO AL12A72 4S1P SANYO MAIN COMMON Made by: Simplo | |
| BOARD | POWER BUTTON BOARD EG50_KB POWER BD 12814-1 PD D | |
| BOARD NIC | FOXCONN 3RD WIFI 1X1 BGN+ BT ATHEROS WB335 | |
| BOARD NIC | LITEON 3RD WIFI 1X1 BGN+ BT ATHEROS WB335 1X1 BGN | |
| BOARD OTHER | USB 2.0 BOARD | |
| CABLE | TOUCHPAD CABLE | |
| CABLE | POWER BUTTON BOARD CABLE EG50KB | |
| CABLE | WIRELESS ANTENNA MAIN LEFT | |
| CABLE | POWER CORD 7A 125V US BK 1M | |
| CABLE | CABLE, CAMERA & MICROPHONE | |
| CABLE | CABLE LCD LCD CABLE JS FOR EA50 | |
| CABLE | CABLE HDD EA50 HDD CABLE | |
| CABLE | CABLE DC-IN 65W | |
| CAMERA | CAMERA CHICONY HD CH HN162 SP2082 P/N: 1HY4ZZZ020H | |
| CAMERA | CAMERA 1.0M_HD CHICONY CNFB1D921004971LH | |
| CAMERA | CAMERA, SUYIN HD SY_HN162_RT P/N: 1HY4ZZZ010K | |
| CAMERA | CAMERA 1.0M_HD CHICONY CNFB1D721004971LH | |
| CAMERA | CAMERA 1.0M_HD SUYIN HF1016-T821-HN01 | |
| CAMERA | CAMERA 1.0M_HD SUYIN HF1016-A21U-OV02 | |
| COVER | LOWER CASE W/ USB 2.0 BOARD CABLE & SPEAKER LOWER CASE W/ USB 2.0 BOARD CA | |
| HARDWARE | LCD HINGE LEFT | |
| HARDWARE | LCD HINGE RIGHT | |
| HARDWARE.MISC. | ODD BRACKET COVER BRACKET ODD | |
| HARDWARE.MISC. | CPU HEATSINK W/FAN FOR UMA ASSY_THM_UMA_FCN FCN_EA40_KB | |
| HDD | HDD 750GB 5400RPM SATA 3 8MB 2.5" 9.5MM 4K WD7500BPVX, ML500M, 500G/P WD LF F/W:01.01A01 | |
| HDD | HDD 750GB 5400RPM SATA 2 8MB 2.5" 9.5MM 4K MQ01ABD075 TOSHIBA AQUARIUS-B 500G/P ACER CODE LF+HF F/W:AX003J P/N: MQ01ABD075 | |
| KEYBOARD | KEYBOARD CHICONY TM7T_G11B TM7T INTERNAL 17 STANDARD 106KS BLACK ALA-SPANISH Y2011 GTW_PB LEGEND WIN 8 | |
| LCD | LCD LED 15.6W WXGA GLARE CMI N156BGE-E41 LF 200NIT 10MS 650:1 (HD LCD : 3.8MM) | |
| LCD | LCD LED 15.6W WXGA GLARE LPL LP156WH3-TPS1 LF 200NIT 16MS 400:1 | |
| LCD | LCD LED 15.6W WXGA GLARE AUO B156XW04 V8 LF 200NIT 8MS 500:1 | |
| MAINBOARD | MAINBOARD EA50/EG50_KB UMA AMD LF CPU A6-5200 BGA 2.0G W/RTC BATTERY & DIMM SOCKET*2 & RJ45 LED (FOR AMD SOLUTION) | |
| MAINBOARD | MAINBOARD EA50/EG50_KB UMA AMD LF CPU A6-5200 BGA 2.0G W/RTC BATTERY | |
| MAINBOARD | IC CPU KABINI A6-5200 BGA2.0GHZ 25W4C | |
| ODD | ODD DVD/RW SUPER-MULTI DRIVE 9.0MM TRAY 8X SATA HLDS GU71N LF W/O BEZEL FRIMWARE: 1.01 DVD/R/RW SMULTI 12.7MM TRAY 8X ODD DVD-RW 9.0 TL HLDS GU71N | |
| ODD | ODD DVD/RW SUPER-MULTI DRIVE 9.0MM TRAY 8X SATA PANASONIC UJ8D2QBAA2-B LF W/O BEZEL DVD/R/RW SMULTI 9MM TRAY 8X ODD DVD-RW 9.0 TL UJ8D2QBAA2-B | |
| PLASTIC | UNILOAD COVER | |
| PLASTIC | LED LCD COVER 15.6" IMR SILVER W/ MICROPHONE & GATEWAY LOGO NONE 3G FOR 3.8MM HD LCD | |
| PLASTIC | LCD BEZEL 15.6" BLACK W/ CCD HOLE & GATEWAY LOGO | |
| PLASTIC | ASSEMBLY UPPER CASE BLACK IMR W/ TOUCHPAD | |
| PLASTIC | ODD BEZEL | |
| PLASTIC | SD DUMMY CARD | |
| SPEAKER | SPEAKER |
Downloads
Specifications
| Model P/N: | NX.Y2ZAL.002 / NXY2ZAL002 |
| Release date (year): | 2013 |
| Quick specs: | NE52203M-MX W8SL64W13/A6-5200/BT/6G/750GB/4L2.5/15.6 NE52203m-65206G75Mnsk W8SL64W13MX4 UMACsk_3U 4G+2G/750/4L2.5/R/CB_GNBT_HD_Rs_ESN1RTM |
| Processor & Chipset | |
|---|---|
| Processor Manufacturer: | AMD |
| Processor Type: | A-Series |
| Processor Model: | A6-5200 |
| Processor Speed: | 2 GHz |
| Processor Core: | Quad-core (4 Core) |
| Cache: | 2 MB |
| 64-bit Processing: | Yes |
| Memory | |
| Standard Memory: | 6 GB |
| Maximum Memory: | 8 GB |
| Memory Technology: | DDR3L SDRAM |
| Number of Total Memory Slots: | 2 |
| Memory Card Reader: | Yes |
| Memory Card Supported: | SD |
| Storage | |
| Hard Drive Capacity: | 750 GB |
| Hard Drive Interface: | Serial ATA |
| Hard Drive RPM: | 5400 |
| Optical Drive Type: | DVD-Writer |
| Display & Graphics | |
| Screen Size: | 39.6 cm (15.6") |
| Display Screen Type: | LCD |
| Display Screen Technology: | UltraBright |
| Aspect Ratio: | 16:9 |
| Screen Mode: | HD |
| Screen Resolution: | 1366 x 768 |
| Backlight Technology: | LED |
| HDCP Supported: | Yes |
| Graphics Controller Manufacturer: | AMD |
| Graphics Memory Technology: | DDR3 SDRAM |
| Graphics Memory Accessibility: | Shared |
| TV Card: | No |
| Network & Communication | |
| Wireless LAN: | Yes |
| Wireless LAN Manufacturer: | Atheros |
| Wireless LAN Model: | WB335 |
| Wireless LAN Standard: | IEEE 802.11b/g/n |
| Ethernet Technology: | Gigabit Ethernet |
| Bluetooth: | Yes |
| Built-in Devices | |
| Front Camera/Webcam: | Yes |
| Microphone: | Yes |
| Finger Print Reader: | No |
| Speakers: | Yes |
| Interfaces/Ports | |
| HDMI: | Yes |
| Total Number of USB Ports: | 3 |
| Number of USB 2.0 Ports: | 2 |
| Number of USB 3.0 Ports: | 1 |
| VGA: | Yes |
| Network (RJ-45): | Yes |
| Audio Line Out: | Yes |
| Software | |
| Operating System Platform: | Windows |
| Operating System: | Windows 8 |
| Operating System Architecture: | 64-bit |
| Input Devices | |
| Keyboard: | Yes |
| Pointing Device Type: | TouchPad |
| TouchPad Features: | Multi-touch Gesture |
| Battery Information | |
| Number of Cells: | 4-cell |
| Battery Chemistry: | Lithium Ion (Li-Ion) |
| Battery Capacity: | 2500 mAh |
| Battery Energy: | 37 Wh |
| Maximum Battery Run Time: | 4.50 Hour |
| Power Description | |
| Maximum Power Supply Wattage: | 65 W |
| Physical Characteristics | |
| Height: | 25.3 mm |
| Width: | 381.6 mm |
| Depth: | 256 mm |
| Weight (Approximate): | 2.40 kg |
| Miscellaneous | |
| Package Contents: |
|
| Additional Information: | Wireless LAN: Acer Nplify 802.11b/g/n |
| Certifications & Standards: | ACPI 3.0 |
| Security Features: |
|
Warranty
To see warranty information, enter a valid serial number or SNID first here
