Summary
Want to buy one? Click
◄ [Buy Options]
Need help? Click◄ [Help & Support]
Want to buy service / replacement / upgrade parts? Click◄ [Repair Parts / Upgrades]
Looking for drivers, BIOS utilities or manuals? Click◄ [Downloads]
Need to look up technical specs? Click◄ [Specifications]
Warranty expiry date lookup? Click◄ [Warranty]
Corrupt, damaged or missing operating system (Windows/Linux)? Click◄ [Recovery CD/DVD/USB]
Buy Options
Buy this product from
Buy this product from
Help & Support
Technical Support
In warranty (Limited free support)
• If your device is still under manufacturer's warranty, you are eligible for limited support (free of charge)• Contact your local eMachines office
Out of warranty (Premium paid support)
• Warranty expired? You can still get help!• Professional support by eMachines trained technicians
• Offered via e-mail or live chat, typical response time is 1-2 hours
• Hardware & software problems
• Upgrades & specifications
• Spare parts search
• Only
• Satisfaction guaranteed, you will only be billed once you approve the answers provided
• Enter your question in the form below to get the process started
Repair Parts / Upgrades
Found 23 parts for EL1360-EW10P model (for repairs / spares)
Category | Description | |
|---|---|---|
| BOARD OTHER | FRONT I/O & CARD READER BOARD USB 2.0 2 USB PORT 2 AUDIO PORT | |
| CABLE | HDD SATA CABLE 400MM.BLACK - (90D) CABLE HDD SATA P/N: 50.3BR01.001 | |
| CABLE | POWER CORD 110V 3PIN UL USA - | |
| CABLE | ODD CABLE SATA 1 | |
| CABLE | ODD CABLE SATA CABLE ODD SATA | |
| DVDRW | ODD SUPER-MULTI 16X SATA DVR-219RS PIONEER BLACK BEZEL LF HH DL (WIN7+HF) P/N: DVR-219RS | |
| DVDRW | ODD SUPER-MULTI 16X SATA DH-16ABSH PLDS HH DL LF BLACK BEZEL (HF+WIN7) 16MM TRAY BEZEL P/N: DH-16ABSH | |
| DVDRW | ODD SUPER-MULTI 16X SATA GH70N HLDS LF+HF BLACK BEZEL HH (WIN7) P/N: GH70N | |
| DVDRW | ODD SUPER-MULTI 16X SATA GH60N HLDS LF+HF BLACK BEZEL HH DL (WIN7+HF) P/N: GH60N | |
| HARDWARE | HDD&ODD BRACKET | |
| HARDWARE | FRONT I/O BRACKET | |
| HDD | HDD 500GB 7200RPM SATA 3 16MB 3.5" WD5000AAKX WESTERN DIGITAL LF F/W:17.01H17 - NON 4K P/N: WD5000AAKX | |
| HDD | HDD 500GB 7200RPM SATA 3 16MB 3.5" WD5000AAKX WESTERN DIGITAL LF F/W:15.01H15 (NON 4K) P/N: WD5000AAKX | |
| HDD | HDD 500GB 7200RPM SATA 3 16MB 3.5" ST3500413AS SEAGATE LF F/W:JC45 P/N: ST3500413AS | |
| KEYBOARD | KB EMACHINES 105+ PS/2 KEYBOARD CHICONY KB-0705 BLACK CANADIAN FRENCH ECOOPER W/VISTA | |
| MAINBOARD | MB KIT EL1360 AMD AMD D1 AMD RADEON HD6320 REALTEK RTL8111E V1.0 LF W/IO SHIELDING & CPU_E450 & HEATSINK W/O DIMM | |
| MOUSE / TOUCHPAD | PRIMAX OPTICAL MOUSE PS2 MOFGKO | |
| MOUSE / TOUCHPAD | MOUSE PS2 OPTICAL LOGITECH 2KEY.M-S0004-O W/SCROLL.BLACK LEAD-FREE P/N: 82-225-002015 | |
| PLASTIC | ASSEMBLY FRONT BEZEL FOR CARD READER | |
| PLASTIC | ASSEMBLY UPPER CASE & LOWER CASE W/LED SWITCH CABLE | |
| SPS | PSU CHICONY POWER CPB09-D220R 220W NONE PFC 2 100-127/220-240V POWER SUPPLY 220W PFC PSU 220NPFC(8.5L) CPB09-D220R EuP CP R | |
| SPS | PSU LITE-ON PS-5221-06A2 220W NONE PFC 100-127/220-240V (20 - 24 PIN PWR CONN) POWER SUPPLY 220W PFC SPS NON-PFC 220W (8.5L) EUP PS-5221-06A2 | |
| SPS | PSU DELTA DPS-220UB-3A 220W NONE PFC 100-127/220-240V POWER SUPPLY 220W EUP PFC SPS 220W EUP 115VAC/230V NPFC EUP DPS-22 |
Downloads
Specifications
| Model P/N: | PV.ND4P2.002 / PVND4P2002 |
| Release date (year): | 2012 |
| Quick specs: | EL1360-EW10P + 20" LCD E202HV (PT.ND4P2.002 + ET.DE2HY.006) EL1360_We450 CH PA001 W7HP64eAAC2/AMDE450B/2G*1+1G*1/500G*1/DSM16XS/E20HV/PS2/eCooper/PS2 MSE |
| Processor & Chipset | |
|---|---|
| Number of Processors Supported: | 1 |
| Number of Processors Installed: | 1 |
| Processor Manufacturer: | AMD |
| Processor Type: | E Series |
| Processor Model: | E-450 |
| Processor Core: | Dual-core (2 Core) |
| Processor Speed: | 1.65 GHz |
| Cache: | 1 MB |
| 64-bit Processing: | Yes |
| Chipset Manufacturer: | AMD |
| Chipset Model: | A45 |
| Memory | |
| Standard Memory: | 3 GB |
| Maximum Memory: | 8 GB |
| Memory Technology: | DDR3 SDRAM |
| Memory Standard: | DDR3-1333/PC3-10600 |
| Number of Total Memory Slots: | 2 |
| Memory Card Reader: | Yes |
| Memory Card Supported: | Memory Stick PRO |
| Storage | |
| Number of Hard Drives: | 1 |
| Total Hard Drive Capacity: | 500 GB |
| Hard Drive Interface: | Serial ATA/300 |
| Hard Drive RPM: | 7200 |
| Hard Drive Configuration: | 1 x 500 GB |
| Optical Drive Type: | DVD-Writer |
| Controllers | |
| Controller Type: | Serial ATA |
| Display & Graphics | |
| Screen Size: | 20" |
| Display Screen Type: | Active Matrix TFT Color LCD |
| Screen Mode: | HD+ |
| Screen Resolution: | 1600 x 900 |
| Aspect Ratio: | 16:9 |
| TV Card: | No |
| Network & Communication | |
| Ethernet Technology: | Gigabit Ethernet |
| Modem: | No |
| I/O Expansions | |
| Number of Total Expansion Bays: | 2 |
| Number of External 5.25" Bays: | 1 |
| Number of 3.5" Bays: | 1 |
| Number of Total Expansion Slots: | 2 |
| Number of PCI Express x1 Slots: | 1 |
| Number of PCI Express x16 Slots: | 1 |
| Input Devices | |
| Keyboard: | Yes |
| Pointing Device Type: | Mouse |
| Interfaces/Ports | |
| HDMI: | Yes |
| Total Number of USB Ports: | 6 |
| Number of USB 2.0 Ports: | 6 |
| Network (RJ-45): | Yes |
| Audio Line In: | Yes |
| Audio Line Out: | Yes |
| VGA: | Yes |
| Modem (RJ-11): | No |
| Software | |
| Operating System Platform: | Windows |
| Operating System: | Windows 7 Home Premium |
| Operating System Architecture: | 64-bit |
| Power Description | |
| Maximum Power Supply Wattage: | 220 W |
| Physical Characteristics | |
| Height: | 10.4" (265 mm) |
| Width: | 3.9" (100 mm) |
| Depth: | 14.6" (371 mm) |
| Miscellaneous | |
| Package Contents: |
|
| Certifications & Standards: |
|
Warranty
To see warranty information, enter a valid serial number or SNID first here
