Summary
Want to buy one? Click
◄ [Buy Options]
Need help? Click◄ [Help & Support]
Want to buy service / replacement / upgrade parts? Click◄ [Repair Parts / Upgrades]
Looking for drivers, BIOS utilities or manuals? Click◄ [Downloads]
Need to look up technical specs? Click◄ [Specifications]
Warranty expiry date lookup? Click◄ [Warranty]
Corrupt, damaged or missing operating system (Windows/Linux)? Click◄ [Recovery CD/DVD/USB]
Buy Options
Buy this product from
Buy this product from
Help & Support
Technical Support
In warranty (Limited free support)
• If your device is still under manufacturer's warranty, you are eligible for limited support (free of charge)• Contact your local Acer office
Out of warranty (Premium paid support)
• Warranty expired? You can still get help!• Professional support by Acer trained technicians
• Offered via e-mail or live chat, typical response time is 1-2 hours
• Hardware & software problems
• Upgrades & specifications
• Spare parts search
• Only
• Satisfaction guaranteed, you will only be billed once you approve the answers provided
• Enter your question in the form below to get the process started
Repair Parts / Upgrades
Found 3 parts for MR.JQK11.009 model (for repairs / spares)
Category | Description | |
|---|---|---|
| BOARD OTHER | IR SENSOR BOARD P/N: 5E.0GF08.001 | |
| CABLE | CABLE HDMI 1.8M V1.4 P/N: 5K.0EH03.502 | |
| CABLE | CABLE BALLAST BOARD TO LAMP 3/4P 55MM P/N: 5K.2HV04.001 |
Downloads
Specifications
| Model P/N: | MR.JQK11.009 / MRJQK11009 |
| Technical Information | |
|---|---|
| Projection Method: | Front |
| Platform Supported: | PC |
| Projection System: | DLP |
| Video Compatibility: | HDTV |
| Computer Compatibility: | Mac PC |
| Projection Lens | |
| Minimum Focal Length: | 5.57 mm |
| Maximum Focal Length: | 18.67 mm |
| Minimum Diagonal Image Size: | 26" |
| Maximum Diagonal Image Size: | 25 ft |
| Optical Zoom: | 1.2x |
| Minimum Lens Aperture: | F/1.94 |
| Maximum Lens Aperture: | F/2.06 |
| Minimum Projection Distance: | 39.37" |
| Maximum Projection Distance: | 32.15 ft |
| Lamp | |
| Number of Lamps: | 1 |
| Lamp Type: | UHP |
| Lamp Power: | 240 W |
| Normal Mode Lamp Life: | 4000 Hour |
| Economy Mode Lamp Life: | 10000 Hour |
| ExtremeEco Mode Lamp Life: | 15000 Hour |
| Image | |
| Low Mode Brightness: | 2800 lm |
| Standard Mode Brightness: | 3500 lm |
| Color Supported: | 1.07 Billion Colors (30-bit) |
| Native Resolution: | 3840 x 2160 |
| Graphic Mode: | 4K UHD |
| Maximum Resolution: | 3840 x 2160 |
| Native Aspect Ratio: | 16:9 |
| Compatible Aspect Ratio: | 4:3 |
| Throw Ratio: | 1.47 to 1.76 (61"@78.74") |
| Zoom Ratio: | 1:1.2 |
| Contrast Ratio: | 10,000:1 |
| Uniformity: | 85% |
| Minimum Vertical Sync: | 24 Hz |
| Maximum Vertical Sync: | 120 Hz |
| Minimum Horizontal Sync: | 15 kHz |
| Maximum Horizontal Sync: | 135 kHz |
| Video | |
| Video Signal Standard: | HDTV |
| Audio | |
| Number of Speakers: | 1 |
| Speaker Output Power: | 10 W |
| Speaker Output Mode: | Mono |
| Interfaces/Ports | |
| HDMI: | Yes |
| HDMI Version: | HDMI 2.0 |
| Total Number of HDMI Ports: | 2 |
| Number of USB Ports: | 1 |
| USB: | Yes |
| USB Connector Type: | 1 x Mini-B |
| VGA In: | Yes |
| Number of VGA Inputs: | 1 |
| Number Of Audio Inputs: | 1 |
| Audio Line In: | Yes |
| Number Of Audio Outputs: | 1 |
| Audio Line Out: | Yes |
| Power Description | |
| Input Voltage: | 230 V AC |
| Operating Power Consumption: | 335 W |
| Power Supply: | 100 V AC ~ 240 V AC |
| Physical Characteristics | |
| Form Factor: | Ceiling Mountable |
| Height: | 4.9" |
| Width: | 13.5" |
| Depth: | 10.2" |
| Weight (Approximate): | 8.82 lb |
| Humidity: | 80% Maximum Relative Humidity |
| Fan Noise: | 23 dB Approximate Silent Mode |
| Miscellaneous | |
| Package Contents: |
|
| Optional Accessories: |
|
| Warranty | |
| Limited Warranty: | 1 Year |
| Parts Warranty/Labor: | 3 Month - Lamp |
Warranty
To see warranty information, enter a valid serial number or SNID first here
